4G Cat12 LTE Indoor Global Band CPE, CBRS available, SRT421
NAT/Bridge/Router mode
Web/TRO69/SNMP management
Category 12 High-speed data services
Multi-APN
VolP/VoLTE
Dual band Wi-Fi with internal antennas
Band Lock/EARFCN Lock/PCI Lock/SIM Lock
UL 2CA/DL 4CA
IPv6/IPv4 dual stack
UL 64QAM/DL 256QAM
- Quick Detail
- Description
- Applications
- Specifications
- Basic Info
- Related Products
Quick Detail
Rich router function sembedded
Support CBRS
Description
SRT421 is a highly advanced LTE indoor multi-service product solution specifically designed to meet integrated data, and 802.11 a/b/g/n/ac dual band Wi-Fi access needs for residential, business and enterprise users.
The product supports advanced Gigabit networking and dual bands Wi-Fi AP functionalities. It enables wide service coverage and provides high data throughput and networking features to customers who needs easy broadband access, hot-spot Wi-Fi connectivity.
Applications
Business
Home
Office
Specifications
| RF Specifications | ||||
| Support Bands | FDD B1/3/7/8/20 | |||
| TDD B38/40/41/42/43/48 | ||||
| *Can be customized. | ||||
| Peak Throughput | TDD DL 560Mbps/UL 30Mbps (Config 2:7) | |||
| FDD DL 800Mbps/UL 150Mbps | ||||
| CA | DL Inter/Intra 2CA/3CA/4CA | |||
| UL Inter/Intra 2CA | ||||
| MIMO | DL 4x4 MIMO | |||
| Output Power@25℃ | 23±2 dBm | |||
| LTE Antenna Gain | ||||
| 700M~1G | 1.5G~2.7G | 3.4G~3.8G | ||
| 3dBi | 5dBi | 5dBi | ||
| Wi-Fi Frequency | Wi-Fi Antenna | Wi-Fi Output Power | Wi-Fi Channel BW | Wi-Fi Antenna Gain |
| 2.4G/5GHz | 4 Built-in | [email protected] | 20/40/80 MHz | 3dBi |
| Dual Band | 16dBm@5GHz |
| Hardware Specifications | |
| Chipset | GCT GDM7243A |
| MTK MT7621DA | |
| LTE standard | 3GPP Release 12 CAT12 |
| Flash | GCT GCM7243A - 2Gb |
| MTK MT7621DA - 1Gb | |
| RAM | GCT GDM7243A - 2Gb |
| MTK MT7621DA - 1Gb | |
| Ethernet LAN Port | 2 * LAN: 10/100/1000 auto-sensing, auto-MDI/MDIX |
| Voice POTS Port | 1 * Voice |
| LED | 8 LED Indicators (PWR, Wi-Fi, TEL, NET, RF Signal*4) |
| SIM | 1 * USIM/SIM (3FF) |
| Reset/Reboot Button | Tact Switch |
| LTE Antenna | 4 Built-in |
| Dimensions | 204.5mm x 169 mm x 60mm |
| Weight | < 500g |
| Power Consumption | < 12W |
| Power Supply | AC input 100~240V |
| DC output 12V 2A | |
| Software Function | |
| Operation Mode | NAT mode |
| Route Mode | |
| Bridge Mode | |
| Device Management | TR069 |
| SNMP | |
| WebUI | |
| Software Upgrade - FOTA | |
| Network Protocols and Features | Multi-APN |
| NAT/NATP | |
| SNTP/NITZ | |
| Static Routing | |
| Virtual server and DMZ | |
| DNS relay and DDNS | |
| IGMP snooping and IGMP proxy | |
| DHCP server | |
| IPV4/IPv6 Dual Stack | |
| UPnP | |
| Parents control | |
| VPN | IPsec |
| L2TP over IPsec | |
| GRE over IPsec | |
| L2TP V2/V3 | |
| GRE L2/L3 | |
| PPTP | |
| Security and Firewall | MAC Address Filtering |
| IP Address Filtering | |
| URL Filtering | |
| DDOS | |
| VoIP/VoLTE functions | Call Waiting |
| Call Hold /Resume | |
| Call Forward | |
| Call Transfer | |
| 3-Way conferencing | |
| Caller ID display/blocking | |
| DTMF | |
| FAX/Modem | |
| Wi-Fi functions | Maximum users: 64 |
| Encryption: WPA-PSK (TKIP), WPA-PSK (AES), WPA2-PSK (TKIP), WPA2-PSK (AES) | |
| Hide SSID broadcasting | |
| AP Isolation | |
| Guest network | |
| Appendix-Deliveries | |
| Assembled product | 1 PCS |
| Ethernet cable | 1 PCS |
| Adapter | 1 PCS |
| Quick Start Guide | 1 PCS |
Basic Info
| Place of Origin: | China |
| Brand Name: | Smawave |
| Model Number: | SRT421 |
| Certification: |
CE FCC RoHS REACH WEEE |
| Minimum Order Quantity: | 1 unit |
| Packaging Details: | High-quality corrugated cardboard box |
| Delivery Time: | In Stock and Ready to Ship |
